Featured
More
Spin-dependent edge detection and imaging enabled by optical circularly polarised states
Jiale Chen, Zhao-xian Chen, Zi-xin Zhou, Yan-qing Lu, Jun-long Kou
Published Published online: 06 February 2025,  doi: 10.37188/lam.2025.008

In photonic crystal slab (PCS) structures, the bound states in the continuum (BICs) and circularly polarised states (dubbed C-points) are critical topological polarisation singularities in momentum space that have garnered significant attention owing to their novel topological and optical properties. In this study, we engineered a novel PCS imager featuring two C-points with opposite chirality through symmetry breaking, resulting in maximal asymmetric transmission responses characterised by near-unity circular dichroism (CD) values. By harnessing the chiral selectivity of the C-points, a high-CD PCS imager can provide two sets of optical transfer functions (OTFs) to facilitate both edge detection and bright-field imaging. Notably, one set of OTFs was finely tuned to a Lorentzian line shape to achieve perfect edge detection. We developed a multifunctional imaging system by integrating a PCS imager into a traditional optical system. Both theoretical and experimental demonstrations confirmed that this system provides bright-field and edge-enhanced images with micrometer-scale resolution. Furthermore, these two independent functions can be easily switched by altering the circular polarisation state of the light source.

[HTML FullText](2604) [PDF 7566KB](3375)
Design of multipass cell with dense spot patterns and its performance in a light-induced thermoelastic spectroscopy-based methane sensor
Yufei Ma, Yahui Liu, Ying He, Shunda Qiao, Haiyue Sun
Published Published online: 17 January 2025,  doi: 10.37188/lam.2025.001

In this study, a ray tracing model based on the law of reflection in vector form was developed to obtain the design parameters of multipass cells (MPC) with dense spot patterns. Four MPCs with distinct patterns were obtained using an established mathematical model. An MPC with a four-concentric-circle pattern exhibited the longest optical path length (OPL) of approximately 38 m and an optimal ratio of optical path length to volume (RLV) of 13.8 cm-2. A light-induced thermoelastic spectroscopy (LITES)-based methane (CH4) sensor was constructed for the first time using the developed optimal MPC and Raman fiber amplifier (RFA). A novel trapezoidal-tip quartz tuning fork (QTF) was used as the detector to further improve the sensing performance. The CH4-LITES sensor exhibited an excellent linear response to optical power and CH4 concentration. The minimum detection limit (MDL) of the CH4-LITES sensor reached 322 ppb when the output optical power of the RFA was 350 mW. The Allan deviation of the system indicated that the MDL decreased to 59.5 ppb when the average time was increased to 100 s.

[HTML FullText](2953) [PDF 9411KB](9093)
Meta-device: advanced manufacturing
Borui Leng, Yao Zhang, Din Ping Tsai, Shumin Xiao
Published Published online: 07 March 2024,  doi: 10.37188/lam.2024.005
Metasurfaces are one of the most promising devices to break through the limitations of bulky optical components. By offering a new method of light manipulation based on the light-matter interaction in subwavelength nanostructures, metasurfaces enable the efficient manipulation of the amplitude, phase, polarization, and frequency of light and derive a series of possibilities for important applications. However, one key challenge for the realization of applications for meta-devices is how to fabricate large-scale, uniform nanostructures with high resolution. In this review, we review the state-of-the-art nanofabrication techniques compatible with the manufacture of meta-devices. Maskless lithography, masked lithography, and other nanofabrication techniques are highlighted in detail. We also delve into the constraints and limitations of the current fabrication methods while providing some insights on solutions to overcome these challenges for advanced nanophotonic applications.
[HTML FullText](10091) [PDF 13303KB](4935)
A multi-photon (7 × 7)-focus 3D laser printer based on a 3D-printed diffractive optical element and a 3D-printed multi-lens array
Pascal Kiefer, Vincent Hahn, Sebastian Kalt, Qing Sun, Yolita M. Eggeler, et al.
Published Published online: 06 March 2024,  doi: 10.37188/lam.2024.003

One of the challenges in the field of multi-photon 3D laser printing lies in further increasing the print speed in terms of voxels/s. Here, we present a setup based on a 7 × 7 focus array (rather than 3 × 3 in our previous work) and using a focus velocity of about 1 m/s (rather than 0.5 m/s in our previous work) at the diffraction limit (40×/NA1.4 microscope objective lens). Combined, this advance leads to a ten times increased print speed of about 108 voxels/s. We demonstrate polymer printing of a chiral metamaterial containing more than 1.7 × 1012 voxels as well as millions of printed microparticles for potential pharmaceutical applications. The critical high-quality micro-optical components of the setup, namely a diffractive optical element generating the 7 × 7 beamlets and a 7 × 7 lens array, are manufactured by using a commercial two-photon grayscale 3D laser printer.

[HTML FullText](8898) [PDF 8752KB](3432)
Article
Linear volumetric additive manufacturing of polymer structures via light initiated direct growth
Yizhen Zhu, Shah Md Ashiquzzaman Nipu, Shengyinghao Chen, Xiangjia Li
Accepted  doi: 10.37188/lam.2025.063
[PDF](50)
Additive manufacturing (AM) encompasses a variety of techniques for creating three-dimensional (3D) structures with intricate geometries, including droplet-based and layer-based methods. Among these, vat photopolymerization (VPP), a layer-based AM technology, stands out for its ability to achieve high resolution and relatively low cost. However, traditional VPP techniques face inherent challenges such as the stair-step effect and limited fabrication speed, which constrain their application for seamless, high-throughput manufacturing. To address these limitations, continuous and volumetric photopolymerization approaches have emerged, offering enhanced precision and faster production capabilities. This study introduces a novel linear volumetric printing technique, Light-Initiated Direct Growth (LIDG), which precisely controls light energy distribution in 3D space within a liquid resin. Unlike other methods, LIDG enables curing light to penetrate pre-printed regions, achieving continuous polymerization along the Z-direction. By leveraging controlled light projection, optical energy is manipulated to initiate photopolymerization at targeted voxels, facilitating the rapid and uninterrupted construction of 3D polymer structures. A detailed optical energy distribution model is developed for LIDG, accounting for light absorption and attenuation characteristics within photopolymer resins. Additionally, the effect of resin viscosity on printing quality is systematically analyzed. Demonstrations of LIDG’s capability to fabricate large macro-scale structures with fine micro-scale features underscore its potential for advancing applications, including biomedical devices, optical systems, and soft robotics.
Article
Structural colouring and luminescence anisotropy of perovskite thin films via laser-induced periodic surface structure formation
Aleksandra Furasova, Yaroslava Andreeva, Jiangnan Xing, Xiaohan Chen, Valeriy Kondratev, Qinghao Song, Ivan Vazhenin, Evgeniia Stepanidenko, Vyacheslav Goncharov, Sergei Cherevkov, Dmitry Permyakov, Dmitry Zhirihin, Sergey V. Makarov
Accepted  doi: 10.37188/lam.2025.062
[PDF](49)
Perovskite nanostructured films are essential to create advanced optoelectronic and photovoltaic devices because of the additional degrees of freedom of manipulation by light reflection and structural colouration, as well as by light trapping and localisation, resulting in control of intensity or polarisation of luminescence. In this paper, we report structural colouration and photoluminescence anisotropy in perovskite films deposited on a substrate with laser-induced periodic surface structures (LIPSSs) on a thin TiO2 layer. The LIPSS TiO2 layer improves charge extraction from the perovskite films, confirmed by a time-resolved photoluminescence analysis. The developed method of substrate nanostructuring does not damage the perovskite films, in contrast to direct laser ablation, imprinting by a mould, mechanical scratching with a cantilever, or plasma-chemical etching. Moreover, the LIPSS formation is appropriate for upscaling owing to the high speed of LIPSS writing (2.25 cm2min-1) and uniform surface nanostructuring.
Letter to the Editor
Towards automated manufacturing process chains for freeform optics with effective reference structures
Review
Quantum meta-devices
Shufan Chen, Chang Peng, Yubin Fan, Xiaodong Qiu, Din Ping Tsai
Accepted  doi: 10.37188/lam.2025.059
[PDF](434)

Meta-devices, known for their capability to manipulate light fields at a subwavelength scale, have gained significant traction in the realm of quantum photonics in recent years. They are being utilized in miniaturized applications such as the preparation of quantum light sources and the control and detection of quantum states. In this review, we provide a systematic explanation of the working principles and notable applications of meta-devices in quantum optical information processing, while also outlining potential directions for the future development of quantum meta-devices.

Review
Terahertz endoscopy of hard-to-access objects in the context of neoplasms diagnosis – A review
Gleb M. Katyba, Nikita V. Chernomyrdin, Irina N. Dolganova, Anna S. Kucheryavenko, Qiwu Shi, Polina V. Aleksandrova, Dmitry S. Ponomarev, Sergey V. Garnov, Igor V. Reshetov, Valery V. Tuchin, Vladimir N. Kurlov, Maksim Skorobogatiy, Kirill I. Zaytsev
Accepted  doi: 10.37188/lam.2025.058
[PDF](1001)

Although terahertz (THz) spectroscopy and imaging offer a variety of applications in medical diagnosis of malignant and benign neoplasms, their translation into clinical practice is hampered by the absence of endoscopic systems capable of sensing the THz optical properties of the hard-to-access tissues. In this review, we focus on recent attempts to address this challenge. To better highlight the need for THz endoscopes, we start with a brief overview of THz medical applications, with an emphasis on neoplasms diagnosis. We then consider the two existing principles of THz endoscopy. The first uses the fiber-coupled THz photoconductive antennas (PCAs) for the THz generation and detection in close proximity to a hard-to-access object, where optical fibers are applied to flexibly deliver the laser pump and probe beams to the THz emitter and detector. The key technology of the second approach is the THz optical fibers capable of delivering the THz waves to an analyte and then detecting the reflected and back-propagated THz signal. Despite this approach still lacking the efficient commercially available THz fiber optics, most recent developments pave the way to solve these problems. In this review, several notable examples of THz endoscopic systems based on different guiding mechanisms, material platform, and manufacturing strategies are discussed.

Article
Ultra-long focal depth annular lithography for fabricating micro ring-shaped metasurface unit cells on highly curved substrates
Zhengang Lu, Bowen Luo, Jiubin Tan
Accepted  doi: 10.37188/lam.2025.056
[PDF](1030)

In recent years, metasurfaces on planar substrates have been extensively investigated and methods for their fabrication have been implemented. However, fabricating metasurfaces on highly curved surfaces remains challenging because of the difficulty in achieving precise mechanical positioning on curved geometries using current lithographic techniques. This limits applications that require finer and more accurate structures. This paper introduces a novel lithographic approach for patterning structures on curved surfaces. By leveraging the natural aberration of a convex lens to focus the beams, this approach enables the creation of adjustable ring and split-ring configurations. Ring-shaped patterns with an average structural width of 1.79 µm were exposed, exceeding the resolution of previously reported annular lithography techniques by a factor of 10. Moreover, this approach offers a defocus tolerance that is 10 times greater than that of conventional direct laser writing lithography, thus reducing the influence of positional errors caused by substrate geometry. Consequently, patterns on a photoresist-coated dome were successfully exposed, marking a pioneering achievement. This study paves the way for creating ring-shaped metasurfaces and other structures on highly curved surfaces.

Article
Generating one-dimensional plasmonic arrays by laser-driven self-organization
Yilong Zhou, Quan Jiang, Xiaoqin Wu, Chunyan Zhu, Zhengyang Shen, Yuquan Miao, Lingxiao He, Liwen Xu, Yu-Cheng Chen, Yipei Wang, Yi Xu
Accepted  doi: 10.37188/lam.2025.057
[PDF](1057)

Assembling metal nanoparticles into a well-defined array and constructing strongly coupled hybrid systems enable high-quality resonances with narrow linewidths, which offer new opportunities to circumvent the hurdle of plasmonic losses. Herein, we propose a light-driven approach for generating plasmonic arrays by leveraging the self-organized patterns of tightly confined surface plasmon polaritons in single metal nanowires, which exhibit optimized unit structures, tunable interparticle spacings with supra-wavelength or sub-wavelength periods beyond the diffraction limit, and flexible alignment directions. We theoretically and experimentally show the mechanism of generating field patterns via the interplay of a standing wave and optical beating, followed by the formation of periodic geometries under a spatially modulated temperature distribution. We also fabricate plasmonic arrays on microfibres with diameters down to ~1.4 μm and thereby construct a series of hybrid plasmonic–photonic resonators with narrow-band resonances (~3.9 nm linewidth) as well as a barcode system with high multiplexing capacity. Our results show the potential of simple, low-cost, and high-efficiency fabrication of plasmonic arrays and hybrids that may find applications in plasmonic array lasers, information encryption, and high-resolution distributed sensing.

Review
Research progress and prospects of laser coating technology
Jingjing Xia, Jinlong Zhang, Hongfei Jiao, Xinshang Niu, Xiaochuan Ji, Tao He, Siyu Dong, Jingyuan Zhu, Xinbin Cheng, Zhanshan Wang
Accepted  doi: 10.37188/lam.2025.055
[PDF](1329)

High-power laser coatings play a critical role in enabling optical manipulation in various laser applications, including beam alignment and control in high-power laser systems. These coatings rely on multilayers and microstructures, such as antireflective (AR) and highly reflective (HR) coatings, filters, and beam splitters, to enhance their performance. This review focuses on laser coatings used for manipulating optical fields, their principal limitations, and laser-induced damage in high-power applications. The concepts, principles, and progress made in exploring the optical performance and distinctive functions of the optical coatings and optimising the laser resistance through structural optimisation, material engineering, and defect elimination are highlighted. Finally, future directions for improving the design flexibility, fabrication feasibility, advanced detection techniques for high-resolution defect characterisation, and further consideration of minimising the optical loss are discussed to meet the evolving demands of modern high-power laser systems.

Article
Investigating a corrective online measurement method for the tool influence function in millimetre spot-sized ion beam figuring
Haixiang Hu, Meng Bian, Wa Tang, Peng Ji, Xuejun Zhang
Accepted  doi: 10.37188/lam.2025.050
[PDF](383)
In short-wavelength optics, millimetre spot-sized ion beam figuring (IBF) is an effective method to eliminate form errors with spatial wavelengths ranging from 10 mm to 1 mm. In this case, the full width at half maximum (FWHM) of the tool influence function (TIF) is typically below 2 mm. In IBF, accurate measurement of a small-sized TIF is critical in determining the removal rate and distribution. In existing research, the online measurement of the TIF has been achieved by scanning the beam current density (BCD) distribution with the Faraday cup (FC). However, due to the convolution effect during scanning, this method is not sufficiently accurate for small-sized TIFs, posing considerable limitations to high-precision applications. This paper presents an in-depth analysis of the convolution effect in TIF measurements. The obtained findings are applied to a corrective TIF measurement method and verified by calculation, simulation, and experiment. The results demonstrate that the proposed method can effectively reduce the measurement error. Specifically, for TIFs with FWHMs ranging from 0.5 to 1 mm, the average measurement error of the peak removal rate (PRR) is reduced from 47.4% to 3.1%, and the average error in the FWHM is reduced from 51.7% to 2.6%. The application of this method to a polishing experiment reduces the root-mean-square (RMS) of the aspherical optical mirror from 1.7 nm to 0.4 nm; moreover, the average convergence rate is 76.4%, which is within the target spatial wavelength range of 15 mm to 3.6 mm. Thus, this paper provides practical guidance for millimetre spot-sized IBF, and is promising for application in high-precision optics.
Letter to the Editor
Volume manufacturing of thin-film lithium niobate modulators with bandwidth > 110 GHz based on 4-inch wafer with a quartz handle
Yang Liu, Zihan Zhou, Peiqi Zhou, Changqing Wang, Qiansheng Wang, Ye Liu, Dong Wang, Daigao Chen, Lei Wang, Xi Xiao
Accepted  doi: 10.37188/lam.2025.047
[PDF](1646)
The continuous growth in data centre traffic, especially from artificial intelligence and machine learning workloads, is driving increased single carrier line rates. High-bandwidth electro-optic modulators are essential for supporting 400 Gbit/s per lane transmission. While recent advancements have demonstrated bandwidths greater than 110 GHz at the die level, this throughput is insufficient for current and future applications like data centre optical interconnects. This paper presents a photonic platform based on 4-inch thin-film lithium niobate wafers with a quartz substrate, offering high yield, low loss and high bandwidth. This platform achieves waveguide propagation loss of < 0.4 dB/cm. The thin-film lithium niobate modulators fabricated on this platform can attain a bandwidth exceeding 110 GHz and possess a half-wave voltage (Vπ) lower than 3 V, with the modulator yield reaching 50%. Additionally, by employing deep-ultraviolet lithography and a metal lift-off process, the platform can be extended to larger wafer sizes (e.g., 6 or 8 inches). This significant increase in wafer-level throughput for 110 GHz electro-optic modulators can greatly enhance data centre optical interconnect capabilities.
Article
Reconfigurable Holographic Patterns for Optical Security Multiplexing Fabricated by 3D Spatially Modulated Femtosecond Pulses
Peng Yi, Zhipeng Wang, Lan Jiang, Xiaowei Li, Yang Liu, Taoyong Li, Andong Wang, Zhi Wang, Xiangyu Zhang, Ji Huang, Qunshuo Wei, Jiafang Li, Lingling Huang
Accepted  doi: 10.37188/lam.2025.046
[PDF](700)

Holographic patterns that integrate printings and holograms into a single device have received extensive attention in optical security owing to their attractive aesthetics and concealment. However, the sophisticated structures of metasurface-based optical devices require a time-consuming fabrication process, hindering the practical application of holographic patterns in optical security. In this study, a novel double-layer holographic pattern that employs simple microholes and microvoids as optical modulation units is designed and experimentally demonstrated. The two layers of the structure arrays are synchronously processed in a transparent material through a single serial-stitching of dynamic 3D spatially modulated femtosecond pulses that are proposed for the rapid fabrication of large-area multi-layered patterns. The fabricated holographic pattern appears as a dynamic grayscale image under white light incident at different angles and projects encoded holographic images under laser illumination. By transforming microholes into microcraters by ultrasonic treatment, the reconfiguration of the holographic pattern can be realized based on refractive index modulation using liquid immersion. The proposed reconfigurable holographic patterns with simple structures and visible sizes enable the recoding of multiple pieces of information, making them practical optical security elements with a wide range of applications in anti-counterfeiting and information encryption.

Article
Large-area, high-resolution, flexible x-ray scintillator film based on a novel 0d hybrid cuprous halide
Dandan Li, Linghang Kong, Liping Feng, Jie Su, Xing Guo, Hui Peng, Xue Zhao, Hanyuan Ding, Xueyan Chen, Fei Zhang, Linyuan Lian, Zhifeng Shi, Pengfei Fu, Zhenhua Lin, Jingjing Chang
Accepted  doi: 10.37188/lam.2025.044
[PDF](609)

X-ray scintillation detectors play an irreplaceable role in medical imaging, security inspections, and nondestructive detection. Recently, all-inorganic lead-free metal halide scintillators have attracted attention for addressing the drawbacks of lead-halide perovskites, such as severe self-absorption and toxicity. Nevertheless, high-resolution, flexible, and cost-effective lead-free scintillators are desirable for X-ray imaging applications. In this study, we designed a zero-dimensional hybrid cuprous halide, (MTP)2Cu4I6 (MTP+ represents [C19H18P]+), and synthesized single crystals. (MTP)2Cu4I6 shows intense yellow emission (618 nm) and a large Stokes shift of 185 nm, almost eliminating the effect of self-absorption. As a result, (MTP)2Cu4I6 exhibited a near-unity photoluminescence quantum yield (99.9%) with a light yield of 43800 photons per megaelectron volt. Moreover, (MTP)2Cu4I6 demonstrates an impressive detection performance with a fast response time of 2.18 μs, a good linear response ranging from 0.038 μGyair s-1 to 53.4 μGyair s-1, and a low detection limit of 37.6 nGyair s-1. In a conceptual experiment, large-area flexible (MTP)2Cu4I6/polydimethylsiloxane (PDMS) scintillation films were fabricated to investigate their X-ray imaging performance. The (MTP)2Cu4I6/PDMS film exhibits a high-spatial resolution of 10.2 lp mm-1 when the modulation transfer function is 0.2 and superior flexible detection performance. The short lifetime, high-light yield, low toxicity, and low cost of (MTP)2Cu4I6 facilitate the development of next-generation X-ray scintillators.

Article
Novel suppression strategy of mid-spatial-frequency errors in sub-aperture polishing: adaptive spacing-swing controllable spiral magnetorheological finishing (CSMRF) method
Bo Wang, Feng Shi, Ci Song, Ping Zhou, Xing Peng, Qing Gao, Shuo Qiao, Guipeng Tie, Wanli Zhang, Ye Tian, Dede Zhai, Qun Hao
Accepted  doi: 10.37188/lam.2025.045
[PDF](402)

Ultra-high-precision, computer-controlled sub-aperture polishing technology is crucial for achieving full-band, high-precision optical components. However, this convolution material-removal method introduces a significant number of mid-spatial frequency (MSF) errors, which adversely impact the performance of optical systems. To address this problem, we propose a novel controllable spiral magnetorheological finishing (CSMRF) method that disrupts the mechanism of conventional constant tool influence function (TIF) convolution material removal. In this paper, we leverage the advantages of a time-varying spacing strategy and theoretically analyze how time-varying spacing, combined with the spiral swing process of the TIF, mitigates MSF ripple errors. The time-varying spacing method highlights the importance of controlling the characteristic frequency, whereas the CSMRF method has a smoothing effect on the errors within the MSF band. Our findings confirm that time-varying spacing and spiral swinging have complementary effects in managing MSF errors. Furthermore, by constraining the MSF and specific frequency errors, we identify the optimal combination of adaptive spacing and spiral angle using a genetic algorithm. We apply a non-negative gradient constraint dwell-time solution algorithm based on the Lagrange regularization method to deterministically evaluate the specific MSF error. Using the application of an inertial confinement fusion optical element as an example, we observe a 99.938% decrease in the amplitude of the PSD curve of the mid-frequency ripple error with a spatial period of 1 mm, whereas the mid-frequency PSD curve remains within the standard line. Therefore, the proposed method can effectively control the specific MSF error distribution. This variable convolution kernel (TIF) sub-aperture polishing method provides a new concept for full-band cooperative error control.

Article
A tree-like data structure for sequential and multi-sequential ray tracing
Goran Bastian Baer, Jens Siepmann
Accepted  doi: 10.37188/lam.2025.043
[PDF](273)

In the area of computer-aided optical design most software packages rely on a surface list based data structure. For classical on-axis lenses – such as camera lenses - the list-based data structure is a suitable way for managing lens data. However, for modern high-end optical systems such as off-axis free-form designs, multi-path systems or for accurate tolerance analysis of complex opto-mechanical systems, the list-based approach often reaches its limits. In this paper we present a new tree-like data structure that is able to solve many of the problems that emerge from surface list based data structures.

Article
Photonic control of thermal radiation for protective windows
Yunbin Ying, Jianbo Yu, Weidong Shen, Pintu Ghosh, Min Qiu, Qiang Li
Accepted  doi: 10.37188/lam.2025.034
[PDF](805)

Thermal protection and comfort are essential for instruments and humans, especially in high-temperature scenarios such as fires and steelworks. Existing thermal protective windows absorb external radiation and heat when exposed to thermal sources, thereby failing to provide thermal comfort to users. Herein, we present a nanophotonic-engineered thermal protective window (NETPW) strategy that incorporates a visible-light transparent broadband directional thermal emitter and a low-emissivity coating into commercial polycarbonate (PC) windows. In comparison to a PC window exposed to a 700 K thermal source at a half-view angle of 50°, the proposed NETPW exhibits remarkable temperature reduction (~77.7 ℃) by reflecting external radiation and enhancing directional radiative cooling. Simultaneously, the NETPW effectively inhibits heat emissions toward users, resulting in a significant improvement in thermal comfort, with a user’s sensible temperature reduction of 57 ℃. Moreover, the NETPW exhibits high visible transparency, high-temperature resistance, scratch resistance, and impact resistance. The seamless integration with existing windows provides a novel approach for controlling thermal emission and optimizing energy exchange.

Letter to the Editor
Lensless single-shot multicore fiber endomicroscopy using a single multispectral hologram
Jakob Dremel, Elias Scharf, Sven Richter, Jürgen Czarske, Robert Kuschmierz
Accepted  doi: 10.37188/lam.2025.027
[PDF](4441)

Endoscopes are indispensable for minimally invasive optical applications in medicine and production engineering. The smallest lensless endoscopes often use digital optics to compensate the intrinsic distortions of light propagation of multimode or multicore fibers. However, due to the wavelength dependency of the distortion, the approach is restricted to a narrow spectral range, which prevents multispectral imaging modalities. We employ a spatial light modulator with a high stroke above 2

\begin{document}$ \pi $\end{document}

, to generate a hologram which minimizes overall phase distortion for multiple spectral bands. This enables lensless multicore fiber single-shot RGB endoscopy, for the first time in the world. Many applications in advanced manufacturing and biomedicine such as in vivo tissue classification are enabled.

Article
Femtosecond laser fabrication of black quartz for infrared photodetection applications
Raffaele De Palo, Annalisa Volpe, Pietro Patimisco, Andrea Zifarelli, Angelo Sampaolo, Antonio Ancona, Hongpeng Wu, Vincenzo Spagnolo
Accepted  doi: 10.37188/lam.2025.026
[PDF](1347)

Quartz tuning forks have been recently employed as infrared photodetectors in tunable laser diode spectroscopy because of their high responsivities and fast response time. As for all sensitive elements employed for photodetection, the main drawback is the limited bandwidth of their absorption spectrum. For quartz crystals, the high absorptance for wavelengths above 5 µm guarantees excellent performance in the mid-infrared range, that cannot be easily extended in the visible/near-infrared range because of its transparency from 0.2 to 5 µm. In this work, we report on the development of a laser surface functionalization process to enhance the optical absorption of quartz crystals, named hereafter Black Quartz, in the 1-5 µm spectral range. Black Quartz consists of surface modification of quartz crystal by ultra-fast-pulsed-laser-processing to create localized matrices-like patterns of craters on top. The surface modification decreases the transmittance of quartz in the 1-5 µm range from > 95% down to < 10%, while the transmittance above 5 µm remains unchanged. The Black Quartz process was applied on two quartz-tuning-forks mounted in a tunable laser diode spectroscopy sensor for detecting two water vapor absorption features, one in the near infrared and the other one in the mid-infrared. A comparable responsivity was estimated in detecting both absorption features, confirming the extension of the operation in the near-infrared range. This works represents an important and promising step towards the realization of quartz-based photodetector with high and flat responsivity in the whole infrared spectral range.

Article
More
Enhancing the MA-free mixed halide perovskite efficiency and stability through bi-solvent engineering approach
Sofia A. Dzhouse-Ivanina, Atyom V. Novikov, Piotr Griscenco, Ilya N. Krupatin, Marina M. Tepliakova, et al.
Published Published online: 25 July 2025,  doi: 10.37188/lam.2025.039
Perovskite photovoltaics upholds the most prominent position in the field of tandem technology development. In this aspect, the creation of perovskite material with suitable bandgap (≥ 1.65 eV) is necessary. And in order to achieve the best device characteristics, the high-quality film formation is crucial. To get a high-quality film, the solvent engineering approach stays at the forefront. However, although the solvent engineering was well discussed for such conventional material as MAPbI3, the field of wide bandgap perovskite materials is still lacking in this area. This paper presents the solvent engineering approach to improve the efficiency and stability of the conventional wide bandgap perovskite material Cs0.17FA0.83PbI1.8Br1.2. Here we utilize several solvents such as traditional N,N-dimethylformamide, dimethyl sulfoxide, N-methyl-2-pyrrolidone and acetonitrile. It was demonstrated that implication of any binary DMF-X solvent improves the solar cell efficiency compared to the pure DMF solution, but the ratio of the X solvent is unique for every X and the foundation for the X influence is also unique. The addition of 2.4 M of DMSO is considered the best to improve the stability and efficiency of laboratory devices, however implementation of AcN allowed to produce 25 cm2 mini-modules with the PCE reaching 10%.
[HTML FullText](267) [PDF 4533KB](695)
Creating ground-based telescopes for imaging interferometry: SELF and ELF
Jeff Kuhn, Nicolas Lodieu, Rafael Rebolo López, Natalia Arteaga-Marrero, Ian Cunnyngham, et al.
Published Published online: 10 July 2025,  doi: 10.37188/lam.2025.033
The largest ground-based telescopes will be much larger than their space-based counterparts far into the future. Remote sensing problems that can take advantage of active and adaptive wavefront control that correct the incoming atmospherically distorted optical wavefront can benefit from very large ground-based telescopes that have other important advantages. For example, their much lower cost (typically one or two orders of magnitude less) and shorter time-to-completion can be compelling. For optical or IR problems that require high angular resolution and large photometric dynamic range we suggest that techniques that make use of photonics, machine learning, or additive manufacturing may even enable less expensive specialized telescopes that are larger than what astronomers are currently building. The Instituto de Astrofísica de Canarias (IAC) recently began a 5 year program with support from the European Union called the Laboratory for Innovation in Opto-mechanics. Its goal is to show how technology innovations can enable less costly and larger telescopes, in particular, aimed at the problem of finding extrasolar life within a few parsecs of the Sun.
[HTML FullText](319) [PDF 7089KB](2842)
Review
More
Application of fluorescence lifetime imaging-integrated deep learning analysis for cancer research
Vibha Kamath, Vyasraj G Bhat, Gagan Raju, Yury V. Kistenev, Nirmal Mazumder
Published Published online: 05 August 2025,  doi: 10.37188/lam.2025.049
Fluorescence lifetime imaging microscopy (FLIM) has emerged as a transformative imaging technique in cancer research, offering quantitative insights into cellular metabolism, tumor microenvironments, and therapeutic responses. By measuring the fluorescence lifetimes of metabolic cofactors such as NADH and FAD, FLIM facilitates the analysis of cancer-specific metabolic reprogramming and heterogeneity. Integration with deep learning further enhances FLIM’s diagnostic and therapeutic potential, enabling high-resolution imaging, automated data analysis, and biomarker identification. This review provides a comprehensive overview of the principles and technological advancements of FLIM, highlighting its applications in cancer diagnostics, drug delivery, and therapy, as well as its integration with deep learning to increase imaging precision and data interpretation. Challenges such as high costs, high computational complexity, and the need for standardized imaging protocols are also addressed. By bridging FLIM with cutting-edge computational techniques, this review highlights its potential to revolutionize cancer research, paving the way for early diagnosis, personalized therapies, and deeper insights into tumor biology.
[HTML FullText](130) [PDF 5063KB](526)
Overview of advanced optical manufacturing techniques applied in regulating laser damage precursors in nonlinear functional KHxD2-xPO4 crystal
Jian Cheng, Guang Chen, Mingjun Chen, Linjie Zhao, Qiao Xu, et al.
Published Published online: 30 July 2025,  doi: 10.37188/lam.2025.048
Nonlinear KHxD2-xPO4 crystal optics, e.g. second/third-harmonic generators, are components of high-energy/power laser facilities, which deliver and convert 1ω, 2ω, and 3ω lasers to obtain extreme fusion ignition conditions (high pressures, high temperatures, etc.). A laser facility requires extremely high-precision and defect-free KHxD2-xPO4 optics with meter-sized apertures to control laser beams temporally, spatially, and spectrally, yielding great ultra-precision manufacturing challenges. Meanwhile, when irradiated by intense laser pulses, laser damage precursors (e.g. manufacturing-induced micro-cracks, scratches, and debris) in the optics would spark off laser-induced surface damage and damage growth, which have been the bottleneck problems preventing the promotion of the output energies of these laser facilities. Under this circumstance, a variety of advanced optical manufacturing techniques have been developed to regulate these precursors to improve the laser damage resistance of the optics. However, the damage thresholds (8–9 J/cm2) of these optics are still far below the intrinsic threshold of the KHxD2-xPO4 (147–200 J/cm2). Furthermore, the batch engineering applications of these techniques remains challenged by the meter-sized apertures of the optics and their soft-brittle, easily deliquescent, anisotropic, and temperature-sensitive material properties, among others. This work summarises the development of state-of-the-art advanced manufacturing techniques and their problems applied in regulating laser damage precursors in the functional KHxD2-xPO4 optics. Because of their soft-brittle, deliquescent, anisotropic nature, etc., these crystal optics are difficult to cut, and new damage precursors (i.e. corrosion, debris, tool marks) could be introduced in the manufacturing processes. The challenges and their solutions are emphatically discussed and analysed in this paper. The latest development trends for the manufacture of high-performance KHxD2-xPO4 optics with high laser damage resistance are also explored. This work could provide basis and guidance for the function-oriented high-performance manufacturing of KHxD2-xPO4 optics and other functional optics with similar material properties, advancing the development of high-energy/power laser facilities.
[HTML FullText](390) [PDF 14123KB](556)
News & Views
More
Solution-processed material innovation is sparking a research boom on X-ray imaging techniques
Haotong Wei
Published Published online: 04 August 2025,  doi: 10.37188/lam.2025.036
X-ray-responsive materials are often expensive and limited because of the monopolistic and complex high-temperature crystallisation technology required. Solution-processed material innovation offers a low-cost and vast design space for a new generation of X-ray detectors aimed at for high X-ray imaging performance.
[HTML FullText](83) [PDF 3219KB](35)
Specialty optical-fibre sensors enable real-time contact measurement of multiple physiological parameters: towards all-fibre wearable devices
Daniele Tosi, Carlos Marques, Arnaldo Leal-Junior, Aliya Bekmurzayeva
Published Published online: 30 July 2025,  doi: 10.37188/lam.2025.054
The real-time measurements of surface physiological parameters, such as body temperature, cardiorespiratory rates, and sweat, is of increasing importance in healthcare. Optical fibres can offer an effective solution for contact sensing, as they enable multi-parameter and multi-point sensing while maintaining a compact form factor. Recent advances using chalcogenide and other specialty fibres represent a substantial step towards all-fibre wearable devices.
[HTML FullText](297) [PDF 2091KB](64)
Surface lattice resonance promotes high-momentum, large-area 2D emission enhancement
Jiepeng Song, Qing Zhang
Published Published online: 29 July 2025,  doi: 10.37188/lam.2025.052
Recent progress in harnessing surface lattice resonance within a van der Waals material–Au slot lattice hybrid platform has enabled a 32-fold enhancement in two-dimensional photoluminescence over an 800 μm2-area, which is promising for realising scalable atomically thin light-emitting devices.
[HTML FullText](143) [PDF 6763KB](51)
A multifunctional optoelectronic memristor for in-memory computing
Yi Ren, Yongji Wang, Sha Zhu, Ning Hua Zhu
Published Published online: 25 July 2025,  doi: 10.37188/lam.2025.053
An amorphous Ga2O3 versatile memristive device has been fabricated to realise four-in-one functionality, merging multibit memory, logic operation, light detection, and neuromorphic computation.
[HTML FullText](218) [PDF 1975KB](75)
